BRZ Viper 60V 4500W Electric Dirt Bike 14/12
BRZ Viper 60V 4500W Electric Dirt Bike 14/12
Available in stock (116)
For off-road use only. Not road legal.
The BRZ Viper 14/12 combines a 60V 4500W QS motor with a 60V 27Ah lithium battery and 14-inch front and 12-inch rear wheels. It has a 750mm seat height, front and rear hydraulic hand brakes, and three speed settings: 25, 45 and 65km/h.
This model has an instrument panel, with no headlight. The specified range is 60km per charge at 35km/h.
Motor, battery and drive
- Motor: QS 120-60H, 60V 4500W.
- Battery: 60V 27Ah lithium battery with 80A BMS.
- Controller: Fardriver NS12 with external Bluetooth.
- Charger: 67.2V 3.0A lithium battery charger.
- Transmission: Chain drive.
- Front/rear gear ratio: 11/60.
- Chain: 420 chain with 114 links.
- Speed settings: Gear 1: 25km/h; gear 2: 45km/h; gear 3: 65km/h.
- Range per charge: 60km at 35km/h.
Wheels, brakes and suspension
- Wheels and tyres: Front 60/100-14; rear 80/100-12. C-type disc/drum hub.
- Brakes: Front and rear hydraulic hand brakes, with no brake cutoff.
- Front suspension: Inverted hydraulic aluminium front fork, 690mm, 39/42mm.
- Rear suspension: Hydraulic damping iron rear shock, 270mm.
Dimensions and equipment
- Wheelbase: 1090mm.
- Seat height: 750mm.
- Minimum ground clearance: 240mm.
- Bike dimensions: 1550 × 700 × 980mm.
- Net weight: 59kg.
- Lights: Instrument panel only, no headlight.
- Display: Instrument panel.
Packing specifications
- Packing dimensions: 1310 × 380 × 660mm.
- Gross weight: 70kg.
Bike Specifications
Bike Specifications
Manufacturer model: HP132E 14/12
MOTOR: QS 120-60H MOTOR, 60V 4500W
BATTERY: 60V27AH LITHIUM BATTERY, BMS 80A
CONTROLLER: FARDRIVER CONTROLLER NS12, EXTERNAL BLUETOOTH
CHARGER: 67.2V 3.0A LITHIUM BATTERY CHARGER
GEAR RATIO (FRONT/REAR): 11/60
CHAIN: 420 CHAIN WITH 114 LINKS
TRANSMISSION: CHAIN DRIVE
WHEELS: F: 60/100-14 R: 80/100-12 (C-TYPE DISC/DRUM HUB)
FRONT&REAR BRAKE SYSTEM: FRONT AND REAR HYDRAULIC HAND BRAKES (NO BRAKE CUTOFF)
FRONT SUSPENSION: INVERTED HYDRAULIC ALUMINUM FRONT FORK 690MM, 39/42MM
REAR SUSPENSION: HYDRAULIC DAMPING IRON REAR SHOCK 270MM
RANGE PER CHARGE: 60KM (AT 35KM/H)
SPEED: GEAR 1: 25KM/H, GEAR 2: 45KM/H, GEAR 3: 65KM/H
WHEELBASE: 1090MM
SEAT HEIGHT: 750MM
MIN GROUND CLEARANCE: 240MM
NET WEIGHT: 59KGS
GROSS WEIGHT: 70KGS
LIGHTS: INSTRUMENT PANEL ONLY, NO HEADLIGHT
DISPLAY: INSTRUMENT PANEL ONLY
BIKE SIZE: 1550×700×980 MM
PACKING SIZE: 1310×380×660 MM
Warranty
Warranty
We stand by our bikes. If any technical fault occurs within 6 months of purchase due to a manufacturing issue, we’ll provide a repair or replacement at no extra cost.
Please note: any damage caused by misuse, tampering, or unauthorized modifications will void the warranty.
Finance
Finance
Flexible finance at checkout. Ride sooner, pay later.
Spread the cost with Pay in 3 or monthly plans of up to 48 months. We work with several lenders so customers across a wide range of credit profiles can be considered – including people who have been declined elsewhere.
Choose the option that fits you
Pay in 3 (Klarna or PayPal) – three interest-free payments. A good option if you can comfortably cover each instalment.
Zopa – monthly plans from 15.9% APR. The best place to start if you have a good credit history.
Snap Finance – assesses affordability, not just your credit score. Try Snap if your credit is limited or fair, or if another lender has already said no.
humm and PayItMonthly — extra monthly options at checkout. Check eligibility before you apply.
How to apply
Select your preferred finance provider at checkout. Zopa and Snap start with a soft search, which does not affect your credit score. Once you are approved, we reserve your bike and get it ready for dispatch.
If one lender declines you, do not reapply to the same provider. Choose a different option at checkout – Snap is set up to consider customers other lenders may not approve.
Fast. Secure. Stress-free.
It is important that you do not take on more borrowing than you can afford. If you miss your repayments this may impact your credit rating and make it more difficult to obtain credit in the future.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
BRZ Viper 14/12 Electric Dirt Bike
The BRZ Viper 14/12 electric dirt bike combines a 60V 4500W QS 120-60H motor with a 60V 27Ah lithium battery with 80A BMS. It has 14-inch front and 12-inch rear wheels, chain drive and front and rear hydraulic hand brakes.
The Fardriver NS12 controller has external Bluetooth. Three speed settings are 25 / 45 / 65 km/h. The stated range is 60 km per charge at 35 km/h.
Dimensions & wheel sizes
Front tyre: 60/100-14
Rear tyre: 80/100-12
Seat height: 750 mm
Minimum ground clearance: 240 mm
Wheelbase: 1090 mm
Net weight: 59 kg
Bike dimensions (L × W × H): 1550 × 700 × 980 mm
Delivery, tracking & returns
For delivery information, read our shipping policy. For return information, read our refund policy.
Packing dimensions (L × W × H): 1310 × 380 × 660 mm
Gross weight: 70 kg
Power, chassis & controls
QS 60V 4500W motor
QS 120-60H motor. Chain transmission with an 11/60 front/rear gear ratio and a 420 chain with 114 links.
Hydraulic suspension
Inverted hydraulic aluminium front fork: 690 mm, 39/42 mm. Hydraulic damping iron rear shock: 270 mm.
60V lithium battery
60V 27Ah lithium battery with 80A BMS. Specified lithium battery charger: 67.2V 3.0A. Stated range: 60 km at 35 km/h.
Three speed settings
Gear 1 / 2 / 3: 25 / 45 / 65 km/h. Fardriver NS12 controller with external Bluetooth. Instrument panel only; no headlight.
BRZ Viper 14/12 key features
FAQs with Answers
What are the BRZ Viper 14/12 speed settings?
What are the BRZ Viper 14/12 speed settings?
Gear 1 / 2 / 3 are 25 / 45 / 65 km/h. The highest specified speed is 65 km/h.
What is the stated range per charge?
What is the stated range per charge?
The stated range is 60 km per charge at a speed of 35 km/h.
Which battery and charger does it use?
Which battery and charger does it use?
It uses a 60V 27Ah lithium battery with 80A BMS. The specified lithium battery charger is 67.2V 3.0A.
What are the wheel sizes and seat height?
What are the wheel sizes and seat height?
Front tyre: 60/100-14. Rear tyre: 80/100-12. Seat height: 750 mm. Wheelbase: 1090 mm. Minimum ground clearance: 240 mm.
What brakes and suspension are fitted?
What brakes and suspension are fitted?
Front and rear hydraulic hand brakes (no brake cutoff). The inverted hydraulic aluminium front fork is 690 mm, 39/42 mm. The hydraulic damping iron rear shock is 270 mm.
Does it have a headlight?
Does it have a headlight?
This model has an instrument panel only and no headlight.
